Configuration¶

Note

This page is relevant only for configuring the Observe Agent on Linux or Windows. Please reivew the Install Observe Agent on Kubernetes page for Kubernetes

All user-provided configuration is in the observe-agent.yaml file. The agent will process this file when it starts and produce a final otel-collector configuration. The default configuration fragments for otel-collector are organized by connection type in the connections folder.

Configuring Via Environment Variable¶

In addition to the observe-agent.yaml file, you can also configure the agent using environment variables. You can override any field in the observe-agent.yaml by setting an env var with the field in all uppercase and substituting :: for . as the delimiter for nested fields. For example, if you wanted to override token, set TOKEN=newtoken. If you wanted to override host_monitoring.enabled, set HOST_MONITORING::ENABLED=true. Environment variables set this way will take precedence over the values in the observe-agent.yaml if they are set.

Enable or Disable Connections¶

These configuration fragments are tied to a specific feature that can be enabled or disabled. For example, in the host_monitoring connection type we have the fragments logs.yaml and metrics.yaml. Each of these is tied to a boolean field in the observe-agent.yaml file and will be included or omitted based on the value there.

Note

Since there’s no guarantee that any given feature will be enabled or disabled, these fragments must be independent of each other and cannot reference anything defined in other fragments. Referencing configuration between fragments could produce a broken otel-collector configuration.

Overriding existing OTEL Collector Configuration¶

You can also override existing components that are defined in the default fragments. To do so, find the name of the component you want to override and redefine it in the otel_config_overrides section of observe-agent.yaml. This section will override any prior definitions of components with the same name.

otel_config_overrides:
  exporters:
    debug:
      verbosity: detailed
      sampling_initial: 5
      sampling_thereafter: 200
  service:
    pipelines:
      # This will override the existing metrics/host_monitoring pipeline and output to stdout debug instead
      metrics/host_monitoring:
        receivers: [hostmetrics/host-monitoring-host]
        processors: [memory_limiter]
        exporters: [debug]

`observe-agent.yaml` Schema¶

Field	Default	Description
token		Observe authentication token
observe_url		Observe data collection endpoint
debug	false	Set log level of agent to “DEBUG”
host_monitoring		Specifies options for the Host Monitoring Connection
host_monitoring.enabled	true	Enables Host Monitoring Connection
host_monitoring.logs		Specifies options for the logs component within Host Monitoring
host_monitoring.logs.enabled	true	Enables the logs component within Host Monitoring
host_monitoring.logs.include	[]	Specify file paths from which to pull host logs
host_monitoring.metrics		Specifies options for the metrics component within Host Monitoring
host_monitoring.metrics.host		Specifies options for host level metrics within Host Monitoring
host_monitoring.metrics.host.enabled	true	Enables host level metrics within Host Monitoring
host_monitoring.metrics.process		Specifies options for process level metrics within Host Monitoring
host_monitoring.metrics.process.enabled	false	Enables process level metrics within Host Monitoring
otel_config_overrides		Defines overrides to be added to the OTEL Collector configuration

Note

The observe_url value is composed from https://${OBSERVE_CUSTOMER_ID}.collect.${OBSERVE_INSTANCE}. For example, if you typically login to https://123456789012.observeinc.com, your ${OBSERVE_COLLECTION_ENDPOINT} is https://123456789012.collect.observeinc.com.

Note

Some Observe instances may optionally use a name instead of Customer ID; if this is the case for your instance, contact your Observe Data Engineer to discuss implementation. A stem name will work as is, but a DNS redirect name may require client configuration.

Adding custom OTEL Collector Configuration¶

The top level observe-agent.yaml includes a section for providing additional OTEL collector configuration, otel_config_overrides. For example, to add a new exporter and a new pipeline to use it, you could define both in this section as follows:

otel_config_overrides:
  exporters:
    debug:
      verbosity: detailed
      sampling_initial: 5
      sampling_thereafter: 200
  service:
    pipelines:
      metrics/debug:
        receivers: [hostmetrics/host-monitoring-host]
        processors: [memory_limiter]
        exporters: [debug]

When the agent starts, it adds this section to the otel-collector configuration and loads it.

Fetching EC2 instance’s tags¶

Resource Detection Processor can optionally gather tags for the EC2 instance that the collector is running on.

Note

In order to fetch EC2 tags, the IAM role assigned to the EC2 instance must have a policy that includes the ec2:DescribeTags permission.

Let’s suppose you want to fetch 3 tags from an EC2 instance the Observe Agent is running on.

This otel_config_overrides section will fetch these 3 tags for the EC2 instance above:

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    resourcedetection/cloud:
      detectors: ["ec2"]
      timeout: 2s
      override: false
      ec2:
        # A list of regex's to match tag keys to add as resource attributes can be specified
        tags:
          - ^Service$
          - ^Name$
          - ^Environment$

Once the Observe Agent is runnig with this otel_config_overrides section, you will see the following additional fields under resource.attributes.

"resource": {
    "attributes": {
      ...
      "ec2.tag.Environment": "Staging",
      "ec2.tag.Name": "Observe-Test6",
      "ec2.tag.Service": "Checkout",
      ...
    }
  }

Detecting a `host.id`¶

Resource Detection Processor is used to detect a host.id.

By default, the Observe Agent is configured as follows to detect resource attributes:

...
  resourcedetection:
    detectors: [env, system]
    system:
      hostname_sources: ["dns", "os"]
      resource_attributes:
        host.id:
          enabled: false
  ...
  resourcedetection/cloud:
    detectors: ["gcp", "ecs", "ec2", "azure"]
    timeout: 2s
    override: false
  ...

This configuration maps the instance id for AWS and GCP or the virtual machine id for Azure to the host.id. It is generally effective for cloud providers. However, if the host.id is not detected correctly, you can enable additional settings by updating the configuration as shown below:

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    resourcedetection:
      detectors: [env, system]
      system:
        hostname_sources: ["dns", "os"]
        resource_attributes:
          host.id:
            enabled: true

This adjustment ensures that the host.id is properly detected when the default configuration does not suffice.

Tailing a log file¶

For example, this otel_config_overrides section will tail a log file:

Tailing a log file on Linux

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
    filelog/custom-name:
    # Define directories or files to include here
      include: [/opt/ProductionApp/RiskLogs/**/*.log]
      include_file_path: true
      storage: file_storage
      retry_on_failure:
        enabled: true
      max_log_size: 4MiB
  service:
    pipelines:
      logs/custom-logs:
        receivers: [filelog/custom-name]
        processors: [memory_limiter, transform/truncate, resourcedetection, batch]
        exporters: [otlphttp/observe, count]

Tailing a log file on Windows

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
    filelog/custom-name:
    # Define directories or files to include here
      include: [D:\\Production\ App\\Risk\ Logs\\**\\*.log]
      include_file_path: true
      storage: file_storage
      retry_on_failure:
        enabled: true
      max_log_size: 4MiB
  service:
    pipelines:
      logs/custom-logs:
        receivers: [filelog/custom-name]
        processors: [memory_limiter, transform/truncate, resourcedetection, batch]
        exporters: [otlphttp/observe, count]

Handling multiline log records¶

Multiline configuration in File Log Receiver can be configured to split log entries on a pattern other than newlines.

Let’s suppose you have the following log records, and need to treat multiline log records as one record or one observation.

[2024-11-09T05:47:56.722293Z] INFO: User login successful. User ID: 12345
[2024-11-09T06:00:23.982100Z] WARNING: API request failed.
Error: ConnectionTimeout
Endpoint: /api/data/fetch
Retrying in 10 seconds...
[2024-11-09T06:01:13.742852Z] DEBUG: Starting backup process.
Directory: /data/backup
Estimated files: 543
[2024-11-09T06:02:45.123812Z] ERROR: Failed to load configuration file.
File path: /etc/app/config.yaml
Cause: FileNotFoundError
Stack trace:
    File "/app/main.py", line 23, in load_config
    config = open(config_path, 'r')
FileNotFoundError: [Errno 2] No such file or directory: '/etc/app/config.yaml'

The following line_start_pattern: \[\d{4}-\d{2}-\d{2}T\d{2}:\d{2}:\d{2}\.\d{6}Z\] matches a timestamp format like [2024-11-09T05:47:56.722293Z].

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
    filelog/host_monitoring:
      include:
        - /var/log/**/*.log
        - /var/log/syslog
      include_file_path: true
      storage: file_storage
      retry_on_failure:
        enabled: true
      max_log_size: 4MiB
      operators:
        - type: filter
          expr: 'body matches "otel-contrib"'
      multiline:
        line_start_pattern: \[\d{4}-\d{2}-\d{2}T\d{2}:\d{2}:\d{2}\.\d{6}Z\]

Filtering metrics¶

Filter Processor can be configured to filter metrics. Let’s suppose you’d like to collect metrics with the following conditions only.

starts with process. and ends with .time
starts with system.cpu.
ends with .utilization

If you’d like to filter out metrics with the same conditions above, replace include: with exclude:.

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    filter/metrics:
      metrics:
        include:
          match_type: regexp
          metric_names:
            - process\..*\.time
            - system\.cpu\..*
            - .*\.utilization
  service:
    pipelines:
      metrics/forward:
        receivers: [otlp]
        processors: [resourcedetection, resourcedetection/cloud, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/host_monitoring_host:
        receivers: [hostmetrics/host-monitoring-host]
        processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/agent-filestats:
        receivers: [filestats/agent]
        processors: [resourcedetection, resourcedetection/cloud, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/agent-internal:
        receivers: [prometheus/agent, count]
        processors: [memory_limiter, transform/truncate, resourcedetection, resourcedetection/cloud, batch, filter/metrics]
        exporters: [otlphttp/observe]

If you are collecting process metrics, use the following configuration.

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    filter/metrics:
      metrics:
        include:
          match_type: regexp
          metric_names:
            - process\..*\.time
            - system\.cpu\..*
            - .*\.utilization
  service:
    pipelines:
      metrics/forward:
        receivers: [otlp]
        processors: [resourcedetection, resourcedetection/cloud, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/host_monitoring_host:
        receivers: [hostmetrics/host-monitoring-host]
        processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/host_monitoring_process:
       receivers: [hostmetrics/host-monitoring-process]
       processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch, filter/metrics]
       exporters: [otlphttp/observe]
      metrics/agent-filestats:
        receivers: [filestats/agent]
        processors: [resourcedetection, resourcedetection/cloud, filter/metrics]
        exporters: [otlphttp/observe]
      metrics/agent-internal:
        receivers: [prometheus/agent, count]
        processors: [memory_limiter, transform/truncate, resourcedetection, resourcedetection/cloud, batch, filter/metrics]
        exporters: [otlphttp/observe]

Receiving data from a Splunk Forwarder¶

To use the Observe Agent to receive data from Splunk forwarders, you have a Splunk Enterprise or Cloud Instance alongside either a Splunk Universal Forwarder or a Splunk Heavy Forwarder routing data to your Splunk instance. The Observe Agent will receive data from the forwarder over TCP port 9997. This requires the following configurations for the Observe Agent and Splunk Forwarders.

Observe Agent - TCP Input

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
    tcplog/s2s:
        add_attributes: true
        listen_address: 0.0.0.0:9997
        operators:
            - field: attributes.log_type
              type: add
              value: splunk_tcp
  service:
    pipelines:
      logs/forward:
        receivers: [tcplog/s2s]
        exporters: [otlphttp/observe]

Splunk Forwarder - outputs.conf

[tcpout]
defaultGroup = observeAgent

[tcpout:observeAgent]
server = hostname:9997
compressed = false
useACK = false
sendCookedData = false

Sampling spans or log records¶

Probabilistic Sampling Processor can be configured to sample spans or log.

Sampling spans

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    probabilistic_sampler:
      sampling_percentage: 50.0

  service:
    pipelines:
      traces/forward:
        receivers: [otlp]
        processors: [probabilistic_sampler]
        exporters: [debug]

Sampling log records

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  processors:
    probabilistic_sampler:
      sampling_percentage: 15
  service:
    pipelines:
      logs/forward:
        receivers: [otlp]
        processors: [resourcedetection, resourcedetection/cloud, probabilistic_sampler]
        exporters: [otlphttp/observe, count]
      logs/host_monitoring-file:
        receivers: [filelog/host_monitoring]
        processors: [memory_limiter, transform/truncate, resourcedetection, resourcedetection/cloud, batch, probabilistic_sampler]
        exporters: [otlphttp/observe, count]
      logs/host_monitoring-journald:
        receivers: [journald/host_monitoring]
        processors: [memory_limiter, transform/truncate, resourcedetection, resourcedetection/cloud, batch, probabilistic_sampler]
        exporters: [otlphttp/observe, count]

Collecting metrics from a MongoDB instance¶

MongoDB Receiver can be configured to collect metrics from a MongoDB instance.

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
    mongodb:
      hosts:
        - endpoint: localhost:27017
      username: otel
      password: ${env:MONGODB_PASSWORD}
      initial_delay: 1s
      tls:
        insecure: true
        insecure_skip_verify: true
  service:
    pipelines:
      metrics/mongo:
        receivers:  [mongodb]
        processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch]
        exporters: [otlphttp/observe]

Collecting logs from a MongoDB instance¶

File Log Receiver can be configured to collect logs from a MongoDB instance. Additionally, you can append metadata like host.name to the logs.

# this should be added to the existing observe-agent.yaml
otel_config_overrides:
  receivers:
      filelog/mongod:
         include:
          - /log/mongod.log

  processors:
    resource/mongod:
      attributes:
        - key : host.name
          value: "my_host"
          action: upsert

  service:
    pipelines:
      logs/new-pipeline:
        receivers: [filelog/mongod]
        processors: [memory_limiter,resource/mongod]
        exporters: [otlphttp/observe]

Configuration¶

Configuring Via Environment Variable¶

Enable or Disable Connections¶

Overriding existing OTEL Collector Configuration¶

observe-agent.yaml Schema¶

Adding custom OTEL Collector Configuration¶

Fetching EC2 instance’s tags¶

Detecting a host.id¶

Tailing a log file¶

Handling multiline log records¶

Filtering metrics¶

Receiving data from a Splunk Forwarder¶

Sampling spans or log records¶

Collecting metrics from a MongoDB instance¶

Collecting logs from a MongoDB instance¶

`observe-agent.yaml` Schema¶

Detecting a `host.id`¶
