Install on Amazon ECS (EC2)

These steps guide you through building a custom Docker image of the Observe Agent with a configuration file, pushing that image to Amazon ECR, creating an ECS task definition that uses it, and finally running it as a service to collect container logs, metrics and traces from your ECS Cluster.

Installation

Prerequisites

Verify the following requirements are met:

AWS CLI installed and configured
Access to an ECS cluster running on EC2
Permissions to create and manage Amazon ECR repositories and CloudWatch log groups
Proper IAM roles for ECS tasks and execution (including permissions for CloudWatch Logs and ECR)

Prepare the Observe Agent configuration

Create the observe-agent.yaml configuration file:

# Observe data token (ex: a1b2c3d4e5f6g7h8i9k0:l1m2n3o4p5q6r7s8t9u0v1w2x3y4z5a6)
token: "${TOKEN}"

# Target Observe collection url (ex: https://123456789012.collect.observeinc.com/)
observe_url: "${OBSERVE_URL}"

self_monitoring:
  enabled: true

host_monitoring:
  enabled: false
  logs:
    enabled: false
    include:
  metrics:
    host:
      enabled: false
    process:
      enabled: false

forwarding:
    enabled: true
    metrics:
        output_format: otel

otel_config_overrides:
  receivers:
    otlp:
      protocols:
        grpc:
          endpoint: 0.0.0.0:4317
        http:
          endpoint: 0.0.0.0:4318
    awsecscontainermetrics:
      collection_interval: 20s
    filelog/ecs:
      include: [/var/lib/docker/containers/**/*.log]
      include_file_path: true
      storage: file_storage
      retry_on_failure:
        enabled: true
      max_log_size: 4MiB
  service:
    pipelines:
      metrics/ecs:
        receivers: [awsecscontainermetrics]
        processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch]
        exporters: [otlphttp/observemetrics]
      logs/ecs:
        receivers: [filelog/ecs]
        processors: [memory_limiter, resourcedetection, resourcedetection/cloud, batch]
        exporters: [otlphttp/observe, count]

Build and push the docker image to Amazon ECR

Create the Dockerfile:

📘
Note
To use a specific version, please visit https://github.com/observeinc/observe-agent/releases.

FROM observeinc/observe-agent:latest
COPY observe-agent.yaml /etc/observe-agent/observe-agent.yaml

Build the docker image

docker buildx build --platform=linux/amd64 -t observe-agent:latest .

Create an ECR repository. In the AWS Management Console or via the CLI, create a repository named observe/observe-agent. The repository URI will look like this:

<your_account_id>.dkr.ecr.<your_region>.amazonaws.com/observe/observe-agent

Push the image to ECR

aws ecr get-login-password --region <your_region> | docker login --username AWS --password-stdin <your_account_id>.dkr.ecr.<your_region>.amazonaws.com
docker tag observe-agent:latest <your_account_id>.dkr.ecr.<your_region>.amazonaws.com/observe/observe-agent:latest
docker push <your_account_id>.dkr.ecr.<your_region>.amazonaws.com/observe/observe-agent:latest

Create a CloudWatch log group for the Observe Agent

Before running the task, ensure a CloudWatch log group exists for your agent logs:

aws logs create-log-group --log-group-name /aws/ecs/observe/observe-agent --region <your_region>

Create the ECS task definition

Update the fields below with your values:

Field	Description
`<your_account_id>`	Your AWS account ID.
`<your_region>`	Your AWS region, such as ca-central-1. See Regions.
`<YOUR_INGEST_TOKEN>`	Your instance's ingest token you create from the Add Data for Linux page, such as a1b2c3d4e5f6g7h8i9k0:l1m2n3o4p5q6r7s8t9u0v1w2x3y4z5a6.
`<YOUR_OBSERVE_COLLECTION_ENDPOINT>`	Your Observe collection endpoint URL, such as https://123456789012.collect.observeinc.com/.
`<your_ecs_task_role>`	An IAM role ARN granting necessary permissions to the task.
`<your_ecs_execution_role>`	An IAM role ARN with permissions to read from ECR and write logs to CloudWatch.

📘
Note
Some Observe instances may optionally use a name instead of Customer ID; if this is the case for your instance, contact your Observe data engineer to discuss implementation. A stem name will work as is, but a DNS redirect name may require client configuration.

Make sure the execution role has logs:CreateLogStream and logs:PutLogEvents permissions.

{
    "family": "observe-agent-task",
    "containerDefinitions": [
        {
            "name": "observe-agent",
            "image": "<your_account_id>.dkr.ecr.<your_region>.amazonaws.com/observe/observe-agent:latest",
            "cpu": 100,
            "memory": 512,
            "portMappings": [
              {
                "containerPort": 4317,
                "protocol": "tcp"
              },
              { "containerPort": 4318,
                "protocol": "tcp"
              }
            ],
            "essential": true,
            "environment": [
                {
                    "name": "TOKEN",
                    "value": "<YOUR_INGEST_TOKEN>"
                },
                {
                    "name": "OBSERVE_URL",
                    "value": "<YOUR_OBSERVE_COLLECTION_ENDPOINT>"
                }
            ],
            "mountPoints": [
                {
                    "sourceVolume": "docker_logs",
                    "containerPath": "/var/lib/docker/containers",
                    "readOnly": true
                },
                {
                    "sourceVolume": "docker_sock",
                    "containerPath": "/var/run/docker.sock",
                    "readOnly": true
                }
            ],
            "volumesFrom": [],
            "readonlyRootFilesystem": false,
            "logConfiguration": {
                "logDriver": "awslogs",
                "options": {
                    "awslogs-group": "/aws/ecs/observe/observe-agent",
                    "awslogs-region": "<your_region>",
                    "awslogs-stream-prefix": "ecs"
                }
            },
            "systemControls": []
        }
    ],
    "taskRoleArn": "arn:aws:iam::<your_account_id>:role/<your_ecs_task_role>",
    "executionRoleArn": "arn:aws:iam::<your_account_id>:role/<your_ecs_execution_role>",
    "networkMode": "bridge",
    "volumes": [
        {
            "name": "docker_logs",
            "host": {
                "sourcePath": "/var/lib/docker/containers"
            }
        },
        {
            "name": "docker_sock",
            "host": {
                "sourcePath": "/var/run/docker.sock"
            }
        }
    ],
    "placementConstraints": [],
    "requiresCompatibilities": [
        "EC2"
    ]
}

aws ecs register-task-definition --cli-input-json file://observe-agent-task-definition.json --region <your_region>

Create an ECS service

aws ecs create-service \
  --cluster <your_ecs_cluster_name> \
  --service-name observe-agent \
  --task-definition observe-agent-task \
  --deployment-controller type=ECS \
  --launch-type EC2 \
  --scheduling-strategy DAEMON \
  --region <your_region>

Send application data to Observe

Once the Observe Agent is deployed, configure your application instrumentation or set the OTEL_EXPORTER_OTLP_ENDPOINT environment variable to one of the following addresses to send application telemetry including traces to the Observe Agent.

📘
Note
When setting up the endpoint to send traces, make sure you use the path that your OTLP library requires. Some libraries need traces to go to /v1/traces, while others expect them at the root path /.

OTLP/HTTP endpoint: http://localhost:4318
OTLP/grpc endpoint: http://localhost:4317

See APM instrumentation for more information about how to instrument your app.

If your application is not able to reach the OTLP endpoints above, register the observe-agent ECS service in AWS Cloud Map

Updated about 2 months ago

What’s Next

Use both the Log Explorer and the Metric Explorer to monitor your systems. To analyze your trace data, explore both the Trace Explorer and the Service Explorer.
