AWS-at-scale data ingestion

This document describes how you can get your AWS data into Observe from an AWS-at-scale environment, with multiple accounts across multiple regions, resulting in potentially hundreds of separate account-region combinations.

AWS-at-scale data ingestion architecture

Such a solution requires having all of your AWS child accounts write to a single Observability account:

Write your CloudWatch logs and AWS configurations in one Observability account that holds the central S3 buckets. Then, use CloudFormation or Terraform to push from those central buckets to Observe via Filedrop.
Use Terraform to pull CloudWatch metrics via the Observe poller. Use one poller for each AWS account.

For example:

flowchart LR
%% Direction: Left to Right (Accounts -> Observability -> Observe)

%% =========================
%% SOURCE AWS ACCOUNTS
%% =========================
subgraph SourceAccounts["AWS Child Accounts"]
direction TB

    Prod["Prod Account"]
    Staging["Staging Account"]
    NAcct["N Account"]

end

%% =========================
%% OBSERVABILITY ACCOUNT
%% =========================
subgraph Observability["Observability Account"]
direction TB

    S3Logs["S3 (cwl-logs-central)"]
    S3Config["S3 (aws-config-central)"]
    Poller["Metrics Poller (per account)"]

end

%% =========================
%% OBSERVE PLATFORM
%% =========================
Observe["Observe"]

%% =========================
%% DATA FLOWS
%% =========================

%% CloudWatch Logs and Subscription Filters
Prod -->|"CloudWatch Logs → CWL Subscription Filter (per stream/group)"| S3Logs
Staging -->|"CloudWatch Logs → CWL Subscription Filter (per stream/group)"| S3Logs
NAcct -->|"CloudWatch Logs → CWL Subscription Filter (per stream/group)"| S3Logs

%% CloudWatch Metrics (read by Poller in each account)
Prod -->|"CloudWatch Metrics (read by Poller)"| Poller
Staging -->|"CloudWatch Metrics (read by Poller)"| Poller
NAcct -->|"CloudWatch Metrics (read by Poller)"| Poller

%% AWS Config delivering to central S3
Prod -->|"AWS Config → delivers to central S3 (cross-account)"| S3Config
Staging -->|"AWS Config → delivers to central S3 (cross-account)"| S3Config
NAcct -->|"AWS Config → delivers to central S3 (cross-account)"| S3Config

%% S3 Buckets feeding into Observe
S3Logs -->|"Filedrop"| Observe
S3Config -->|"Filedrop"| Observe

%% Poller sending metrics
Poller -->|"Metrics → Observe"| Observe

Terraform and CloudFormation resources

View the Terraform and CloudFormation resources you will need to set up this data ingestion:

Terraform

CloudWatch Logs, AWS Config: https://registry.terraform.io/modules/observeinc/collection/aws/latest/submodules/stack
CloudWatch Metrics: Poller https://registry.terraform.io/providers/observeinc/observe/latest/docs/resources/poller#cloudwatch-metrics-poller

CloudFormation

https://github.com/observeinc/aws-sam-apps/tree/main

Get CloudWatch logs into Observe

Consolidate your CloudWatch logs to land in one S3 bucket in an AWS Observability account. Observe can ingest the logs from that account using the Observe Forwarder, deployed in the same AWS account.

Perform the following tasks to set this up:

Create a KMS-encrypted S3 bucket, such as cwl-logs-central-<org>, with the desired lifecycle rules, such as 30–90 days hot with Glacier or Glacier Deep Archive storage classes. Be sure to check whether any KMS key policies in the Observability account are denying the S3 bucket objects from being copied when files are sent to our Filedrop.
In each source account, connect your CloudWatch log subscription filters to a Kinesis Firehose (same account) that delivers to the central S3 bucket (cross-account role).
In the Observability account, deploy Add Data for AWS (CloudFormation) or Terraform stack module to read from cwl-logs-central-* and send to Filedrop.

Note that Filedrop prefers larger compressed objects rather than many small files:

Target up to 1 GB per file for optimal ingest.
Each single cell or field inside the file must be at most 16 MB.
Use compression, such as GZIP, to minimize PUT operations and reduce costs.
Balance Firehose buffering (size vs. interval) so you generate fewer, larger objects without delaying data too much.

Get AWS configurations into Observe

Get all your AWS accounts to send their configuration snapshots and change notifications to a single S3 bucket in the Observability account.

Perform the following tasks to set this up:

Enable the AWS configuration in each account or region with delivery channel to aws-config-central-<org> using a cross-account bucket policy. Make sure both the bucket policy and the role trust in source accounts are set; it’s common to do one and forget the other.
In the Observability account, deploy Add Data for AWS (CloudFormation/Terraform) to pick up from that bucket and send to Filedrop.

Get CloudWatch metrics into Observe

Configure a lightweight metrics poller in each AWS account to read the CloudWatch metrics and ship the data to Observe.

Perform the following tasks to set this up:

With Terraform, deploy the poller module once per account with least-privilege IAM, read-only CloudWatch permissions.
Scope namespaces, such as AWS/EC2, AWS/ELB, AWS/Lambda, or custom, to control cost and volume. Be careful using namespaces with many dimensions, as this can cause costs to spike quickly.
Centralize config via Terraform variables and tag resources. For example: Owner=Observability, DataClass=Metrics.

Can I use Control Tower?

This section contains additional information and context to help you decide if you want to use Control Tower to setup a central Observability account.

How does Control Tower fit into this picture?

Control Tower sets up a multi-account AWS organization with guardrails, centralized governance, and predefined “landing zone” accounts. Since Control Tower already creates one central account for storing logs and config, it is possible to extend the Control Tower Log Archive account to also serve as the central Observability account.

Even if you have Control Tower, you may still want to create a separate dedicated Observability account in the following cases:

You don’t want to overload the log archive with additional ingestion pipelines.
You want to clearly separate compliance logs (retention-focused) vs. observability telemetry (operational, shorter retention, more frequent query).

In either case, the central S3 buckets for CloudWatch logs exports and AWS config snapshots reside in one chosen account, and cross-account delivery is handled by bucket policies and roles.

Does Control Tower include all CloudWatch logs from all AWS accounts?

The Control Tower Log Archive account is not a full CloudWatch logs aggregator.

The Log Archive account always collects CloudTrail and optionally Config / VPC Flow Logs, but it does not automatically include all CloudWatch Logs from member accounts. If you want that, you need to set up subscriptions/export pipelines yourself.

What Control Tower Log Archive does by default

When you set up Control Tower, a Log Archive account is created and Organization-level CloudTrail is configured.
All member accounts in the organization send their CloudTrail logs (and optionally VPC Flow Logs, Config snapshots, etc.) into the central S3 bucket in the Log Archive account.
This is focused on compliance and governance logs (security + audit trail).

What Control Tower doesn't include by default

Control Tower does not automatically centralize all CloudWatch Logs log groups, such as Lambda logs, ECS logs, and application logs.
To get those into the Log Archive account, you must configure either of the following:
- Log subscriptions, such as CloudWatch Logs → Kinesis Firehose → central S3 in Log Archive.
- Centralized logging solutions, such as AWS Centralized Logging solution, or custom Terraform/CloudFormation.

Control Tower doesn’t know which CloudWatch log groups you care about, so you have to set up forwarding yourself.

How AWS config fits

Control Tower can enable AWS Config in governed accounts and deliver Config snapshots and compliance records into the Log Archive account’s S3 bucket.
This is separate from CloudWatch Logs, only Config data is included.

Pros and cons to consider

This section compares using a Control Tower Log Archive account versus creating a dedicated Observability account for centralizing logs, metrics, and config.

Control Tower Log Archive account

Review the following considerations for using the Control Tower Log Archive account:

Pros	Cons
Out of the box: Created automatically with Control Tower landing zone. Already has baseline setup for CloudTrail and config delivery. Governance-aligned: Fits neatly into AWS organizations structure; integrates with Service Control Policies (SCPs) and guardrails. Cost efficiency: One less account to manage; no extra billing line item. Security model already in place: Enforced least-privilege, encryption, and lifecycle policies aligned with compliance needs. Single pane for compliance data: Audit/security teams can find CloudTrail and configs in one place.	Scope mismatch: Designed for compliance/audit logs, not necessarily high-volume app telemetry. Retention policies: Typically long (7+ years for audit); may conflict with operational observability needs where 30–90 days is common. Ownership conflict: Often governed by compliance/security teams, not platform/observability teams → friction around change requests. Cost tracking: Mixing compliance and observability data in the same S3 buckets can blur cost attribution.

Pros

Cons

Out of the box: Created automatically with Control Tower landing zone. Already has baseline setup for CloudTrail and config delivery.
Governance-aligned: Fits neatly into AWS organizations structure; integrates with Service Control Policies (SCPs) and guardrails.
Cost efficiency: One less account to manage; no extra billing line item.
Security model already in place: Enforced least-privilege, encryption, and lifecycle policies aligned with compliance needs.
Single pane for compliance data: Audit/security teams can find CloudTrail and configs in one place.

Scope mismatch: Designed for compliance/audit logs, not necessarily high-volume app telemetry.
Retention policies: Typically long (7+ years for audit); may conflict with operational observability needs where 30–90 days is common.
Ownership conflict: Often governed by compliance/security teams, not platform/observability teams → friction around change requests.
Cost tracking: Mixing compliance and observability data in the same S3 buckets can blur cost attribution.

Dedicated Observability account

Review the following considerations for create your own dedicated Observability account:

Pros	Cons
Tailored for telemetry: You can optimize retention, compression, partitioning, and ingestion frequency for ops data (different from compliance requirements). Operational autonomy: Owned by platform/SRE/DevOps teams; changes (Firehose configs, Filedrop integration) don’t require sign-off from audit. Cost isolation: Easy to attribute ingest/storage costs for observability separately from compliance. Flexibility: Can host additional observability tooling (metrics pollers, log processing Lambdas, dashboards) without interfering with governance controls. Future-proof: If you expand to multiple observability vendors or run custom pipelines, the account is already dedicated.	Extra account overhead: Another AWS account to provision, secure, and manage. Duplication risk: You may end up storing the same data twice. For example, config snapshots can be stored in the Log Archive and Observability account. Integration effort: Need to configure cross-account delivery and policies from scratch, whereas such policies for Log Archive are already wired in by Control Tower. Silo danger: If governance teams aren’t looped in, may create fragmented views of org-wide logs.

Pros

Cons

Tailored for telemetry: You can optimize retention, compression, partitioning, and ingestion frequency for ops data (different from compliance requirements).
Operational autonomy: Owned by platform/SRE/DevOps teams; changes (Firehose configs, Filedrop integration) don’t require sign-off from audit.
Cost isolation: Easy to attribute ingest/storage costs for observability separately from compliance.
Flexibility: Can host additional observability tooling (metrics pollers, log processing Lambdas, dashboards) without interfering with governance controls.
Future-proof: If you expand to multiple observability vendors or run custom pipelines, the account is already dedicated.

Extra account overhead: Another AWS account to provision, secure, and manage.
Duplication risk: You may end up storing the same data twice. For example, config snapshots can be stored in the Log Archive and Observability account.
Integration effort: Need to configure cross-account delivery and policies from scratch, whereas such policies for Log Archive are already wired in by Control Tower.
Silo danger: If governance teams aren’t looped in, may create fragmented views of org-wide logs.

Recommendations

Review the following recommendations based on your organization's size and priorities:

Your org	Recommendation
You are a small and/or compliance-driven org.	Stick with Control Tower's Log Archive account, and extend it slightly to add S3 buckets and Firehose targets for CloudWatch logs and config if you’re OK with compliance retention rules and shared ownership.
You are a larger and/or platform-driven org.	Stand up a dedicated Observability account for telemetry pipelines for logs, metrics, and config, while still letting Control Tower’s Log Archive account focus on compliance. This separation avoids operational vs. compliance conflicts.
You're a little of both	Keep CloudTrail and long-term config snapshots in Control Tower's Log Archive. Ship CloudWatch logs and shorter retention, higher volume metrics into an Observability account.
